**Product Specifications:**

**Brand:** BULL

**Model:** Embedded Socket

**Features:**

- Mini and exquisite design

- Dual-color options

- CCC certified

- Embedded design with rotatable plug and tail end

- USB charging port

- Flame-retardant material

- Suitable for narrow spaces

- Compact and elegant design

**Rotatable Design:**

- 90° rotatable plug for flush mounting

- Detachable flat plug for reduced installation gap

**Installation:**

- Rotatable plug for easy wiring in different scenarios

- Compatible with wire organizers for neat cable management

**USB Charging:**

- Convenient 1A charging

- Maximum 2.1A charging current

- Precise current recognition for stable charging

**Safety Features:**

- PC material shell with 750°C flame retardancy

- MAX 2500W power capacity

- Thickened 2-core conductor with 1.0mm² wire diameter

**Durability:**

- Integrated copper strips for 10,000 plug and unplug cycles

**Product Details:**

- **Appearance:** Miniature design

- **Series:** Full-pass, GNQ-Q1031 (White), GNQ-Q1021U (White), GNQ-Q1021D (White), GNQ-Q1031H (Black), GNQ-Q1021UH (Black), GNQ-Q1021DH (Black)

- **Configuration:** Various socket and switch combinations

**Electrical Parameters:**

- Rated Voltage: 250V~

- Maximum Current: 10A

- Maximum Power: 2500W

**Dimensions:**

- Product Length: 1.8 meters

- Product Size: 223×53×29.5mm

**USB Parameters:**

- Input: 100V-240V~

- Output: 5V 2.4A Max

**Standards:** Compliant with GB/T and GB standards

**Installation Information:**

- **Full-Pass Configuration Hole Size:** 53mm, 29.5mm, 223mm

- **Full-Pass 3D Diagram Hole Size:** 194mm, 194mm, $2, R6, 46mm, 46mm, R6, 208mm

**Installation Instructions:**

- Securely fix the embedded socket with screws

- Route the wires through the backboard and into the hole

- Use wire organizers to secure the cables

- Complete the installation by fixing the wires and closing the panel

**Note:** The above specifications are based on laboratory reports from BULL.
